NIBE FIGHTER 1250
List of components
F
1 Miniature circuit-breaker, +1-F1
2 EBV card, current limiter card, +2-E2
3 Thermostat, standby mode, +1-B3
4 Connection, Brine in (KBin)
5 Connection, Brine out (KBut)
7 Service connection, high pressure
8 Switch, 1 – 0 – , +1-S1
9 Terminal block, incoming electricity, +1-X9
10 Contactor, electric addition step 1, +1-K10
15 * Outdoor sensor (UG), GT6, +1-B15
16 Circulation pump,(VB-pump), P2, +0-M16
17 Evaporator, VVX1
18 Condenser, VVX2
19 Three way valve, heating system/hot water heater,
SV2, +0-M19
24 Electrical addition, EL1, +0-R1
25 Temperature limiter, +1-D25
27 Compressor, K1, +3-M1
29 Relay card with power supply unit, +1-E29
32 Display unit, +1-E11
33 High pressure pressostat (HP), GP1, +3-B33
34 CPU-unit, control system, +2-E34
35 Brine pump (KB pump), P1, +0-M35
41 Low pressure pressostat (LP), GP2, +3-B41
42 Service connection, low pressure
48 Expansion valve, SV1
52 * Safety valve, collector side
58 Anode cover (enamel only)
60 EMC-fi lter, +3-Z2
61 Suppression capacitor, +1-C61
63 * Particle fi lter (KBin) R25 int.
65 Drying fi lter
67 Contactor, electric addition step 2, +1-K67
69 Contactor, inverter, +1-K69
70 Connection, heating medium fl ow ø 22 mm ext
71 Connection, heating medium return ø 22 mm ext
72 Hot water circulation (VVC)
Enamel: G 20
Stainless steel: Ø15 mm ext
73 Connection, cold water (CW)
Copper: Ø 22 mm ext
Stainless steel: Ø 22 mm ext
Enamel: G 20
74 Connection, hot water (HW)
Copper: Ø 22 mm ext
Stainless steel: Ø 22 mm ext
Enamel: G 20
75 Venting valve, double jacket
76 Draining, heating system
77 Venting valve, brine system
81 * Particle fi lter (VBR) R20 int.
85 * Connection, level vessel to system, R25 ext.
86 Temperature sensor, Brine in (KBin), GT1, +0-B86
87 Temperature sensor, Brine out (KBut), GT1, +0-B87
88 Temperature sensor, hot water jacket (VVM), GT10,
+2-B88
89
Temperature sensor, heating medium ow (VBF1), GT11,
+0-B89
94 Temperature sensor, heating medium return (VBR1),
GT8, +0-B94
95 Type plate/serial number
96 Type plate, cooling section
99 Cable gland, incoming electricity
100 Knob, setting “Fuse”
101 Knob, setting “Max electric addition”
102 Knob, setting “Max hot water temperature”
110 Temperature sensor, hot gas (HG), GT5, +3-B110
111 Temperature sensor, liquid line, GT3, +3-B111
112 Temperature sensor, bulb, GT4, +3-B112
115 Electric anode (enamel only)
116 Power unit, electric anode (enamel only)
141 Temperature sensor, condenser fl ow (KF), GT7,
+0-B141
142 Temperature sensor, hot water top, GT9, +2-B142
153 Compressor heater, +3-R1
160 Inverter, +3-A1
161 Choke, +3-Z1
162 Card 102, -E1
163 CapBox, +1-C1
* Enclosed
