NIBE FIGHTER 1250
Dimensions
F
A BI II III I II
50 . 0 C
Va rm v at t e nt e mp e r at u r
13.43
1.0
P
A
525
180
400
600
455
145
140
50
45
100
245
640
1750
65
63025-50
5
4
4
5
5
Dimensions and setting-out coordinates
Alternative:
Pipe connection (4, 5) can also be made to the right.
A distance of 800 mm is
needed in front of FIGHTER
1250 and leave 400 mm of
space free to the right and
left of the heat pump for
servicing.
When FLM is fi tted on
FIGHTER 1250 the distance
to the wall should be at least
50 mm.
