12 – English
9.1.7-Radioreceiver
The “SM” radio receiver connector for SMXI or SMXIS type optional radio
receivers has been provided in order to enable the user to control SLIGHT, from
a distance.
For further information consult the radio receiver instructions manual. To insert
the radio receiver, follow the operations indicated in Figure 18. In Table 12 there
is a description of the association between the radio receiver output and the
command that SLIGHT will perform:
TABLE12 -
commandswithtransmitter
Output No. 1 Step-by-Step command (STEP-BY-STEP)
Output No. 2 "Partial opening" command
Output No. 3 "Open" command
Output No. 4 "Close" command
9.1.8-Connectionandinstallationofthebufferbattery
WARNING!
– Electricalconnectionofthebatterytotheunitmustbe
performedexclusivelyaftercompletingallstagesininstallationand
programming,asthebatteryisanemergencypowersupply.
To install and connect up the battery, follow the stages shown in Fig. 19.
9.1.9-ConnectinguptheOviewprogrammer.
The unit has a BusT4 connector for connection of the Oview programming unit
permitting complete, rapid management of installation, maintenance and diag-
nosis of the entire automation mechanism. To access the connector, proceed
as shown in Fig.20 and connect up the connector in the housing provided.
The Oview may be connected to multiple units simultaneously (up to 5 with no
particular precautions, up to 60 with the warnings stated) and may be left con-
nected up to the unit during regular operation of the automation mechanism.
In this case, it may be used to send commands directly to the unit using the
“user” menu. You may also update Firmware. If the unit has a radio receiver
in the OXI family, you may use Oview to access the transmitter parameters
memorized in the receiver.
For more information refer to the instruction manual and the “Opera system
book” manual.
9.1.10-ConnectingtheSolemyosolarenergysystem
WARNING!–Whentheautomationmechanismispoweredbythe
“Solemyo”systemITMUSTNOTBEPOWEREDbytheelectricitygrid
atthesametime.
Refer to the instruction manual provided with the Solemyo system for more
information.
To connect up the Solemyo system, proceed as shown in g.21.
9.2-Specialfunctions
9.2.1-"Alwaysopen"function
The “Always open” function is a control unit feature which enables the user
to control an opening manoeuvre when the “Step-by-Step” command lasts
longer than 2 seconds. This is useful for connecting a timer contact to the
“Step-by-Step” terminal in order to keep the gate open for a certain length of
time, for example. This feature is valid with any kind of “Step-by-Step” input
programming, except for “Close”. Please refer to the “Step-by-Step Function”
parameter in Table 7.
9.2.2-Funzione“Muovicomunque”
In the event that one of the safety devices is not functioning properly or is out of
use, it is still possible to command and move the gate in “Man present” mode.
Please refer to the Paragraph “Control with safety devices out of order” in the
enclosure “Instructions and Warnings for users of the SLIGHT gearmotor” for
further information.
9.2.3-Maintenancenotication
WithSLIGHT the user is warned when the automation requires a mainte-
nance control. The number of manoeuvres after the warning can be selected
from 8 levels, by means of the “Maintenance warning” adjustable parameter
(see table 7).
Adjustment level 1 is “automatic” and takes into consideration the severity of
the manoeuvre, this being the force and duration of the manoeuvre, while the
other adjustments are established based on the number of manoeuvres.
The maintenance request signal is given by means of the ashing light (Flash)
or by the light connected to the S.C.A. output when programmed as a “Main-
tenance light” (see table 9).
The ashing light “Flash” and the maintenance light give the signals indicated
in table 13, based on the number of manoeuvres performed in respect to the
limits that have been programmed.
TABLE13-MaintenancewarningwithFlashandmaintenancelight
Numberofmanoeuvres Flashsignal Maintenancelightsignal
Lowerthan80%ofthelimit
Normal (0.5s on, 0.5s off) On for 2s when opening begins
Between81%and100%of
thelimit
Remains ON for 2s at the start of the manoeuvre then car-
ries on normally
Flashes throughout the manoeuvre
Over100%ofthelimit
Remains ON for 2s at the start and end of the manoeuvre
then carries on normally
Always ashes
