EN
16 – English
TABLE20-LEDsonthecontrolunit’skeys
LED1 Description
OFF During normal operation the device indicates "Automatic Closing" is inactive.
ON During normal operation the device indicates "Automatic Closing" is active.
Flashing • Function programming in progress.
• If it ashes together with L2, it means that the user must carry out the device recognition phase (refer to Paragraph 9.1.6)
LED2 Description
OFF During normal operation the device indicates “Close after photo” is not active.
ON During normal operation the device indicates “Close after photo” is active.
Flashing • Function programming in progress.
• If it ashes together with L2, it means that the user must carry out the device recognition phase
(refer to Paragraph “9.1.6 Recognition of the devices”)
LED3 Description
OFF During normal operation the device indicates “Always close” is inactive.
ON During normal operation the device indicates “Always close” is active.
Flashing • Function programming in progress.
• If it ashes together with L4, it means that the user must carry out the leaf length recognition phase
(refer to Paragraph “6.4 Recognition of the length of the leaf”).
LED4 Description
OFF During normal operation the device indicates “Standby” is inactive.
ON During normal operation the device indicates “Standby” is active.
Flashing • Function programming in progress.
• If it ashes together with L3, it means that the user must carry out the leaf length recognition phase
(refer to Paragraph “6.4 Recognition of the length of the leaf”).
LED5 Description
OFF During normal operation the device indicates “Peak” is inactive.
ON During normal operation the device indicates “Peak” is active.
Flashing Function programming in progress.
LED6 Description
OFF During normal operation the device indicates “Pre-ashing” is inactive.
ON During normal operation the device indicates “Pre-ashing” is active.
Flashing • Function programming in progress.
LED7 Description
OFF During normal operation the device indicates that the CLOSE input activates a closing manoeuvre.
ON During normal operation the device indicates that the CLOSE input activates a partial opening manoeuvre.
Flashing Function programming in progress.
LED8 Description
OFF During normal operation the device indicates that SLIGHT is congured as Master.
ON During normal operation the device indicates that SLIGHT is congured as Slave.
Flashing Function programming in progress.
