Nordson EFD PROPlus Series - Operating Features; PROPlus; PRO Front Panel; PROPlus; PRO Back Panel

PROPlus / PRO Series Automated Dispensing Systems
16 www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.
EMERGENCY STOP
button
START button
SVC USB port (for
software upgrades)
DISPENSER PURGE
button
Power
Switch
PROPlus / PRO Back Panel
Dispenser port (for
dispenser /controller
initiation)
I/O PORT (for
input/output
connections)
RS232-1 port
(connects to the
DispenseMotion
controller)
Ext. Control port (for the
I/O safety plug)
Tactile Laser port (for
the laser and / or tip
detector connections)
Power Inlet
Operating Features (continued)
PROPlus / PRO Front Panel
RS232-2 port
(connects
to the laser
controller)
