4-36 Power-Up and Testing
Item Description
1 Heater On/Off Column
2 Channel (Loop) Name Column
3 Temperature Set Point Column
4 Present Temperature Value Column
5 Message Column
Figure 4-24 Heater Control Window
1
2
3
5
4
