4-10 Power-Up and Testing
4.9 Preliminary System Check
Before powering up the dispensing system, follow the steps below to make sure there is sufficient
clearance for the dispensing head to operate in the dispensing chamber.
CAUTION! The following procedures should only be performed by a trained
service technician.
To check Dispensing Head clearance:
1. With the hood still open, manually move the dispensing head throughout the entire
dispensing chamber making sure that it does not encounter any obstacles during its travel.
2. Make sure the pneumatic and electrical cables do not impede the dispensing head travel and
are not in danger of being pinched or snagged.
3. Check the dispensing valve and bracket to make sure that it is mounted securely.
4. Close the dispensing system hood.
4.10 Component-Level Functional Tests
After initially powering up your dispensing system, all major subsystems must be tested to ensure that
they are ready for operation. This section includes functional tests for the following components:
•
EMO
•
Pneumatic Regulators and Gauges
•
Impingement Air Flowmeters
•
Light Beacon
•
Conveyor and Conveyor Pneumatics
•
Dispensing Head and Accessories
•
Vision System
•
Dispensing Valve Pneumatics
•
Tactile Sensor
•
Purge Station
•
Scale
•
Heater Tooling and Needle Heaters
CAUTION! The following procedures should only be performed by a trained
service technician.
