Specifications 10-1
10 Specifications
10.1 Overview
Facility requirements and specifications are listed in 0HTable 10-1 to 1HTable 10-4. These specifications are
intended as a convenient reference for installation, system relocation, planning and operation. Meeting the
requirements will ensure reliable operation and safety of the dispensing system.
WARNING! CAUTION!
To ensure optimal performance and safety, it is necessary to install the
dispensing system in a facility that meets the necessary requirements listed in
2HTable 10-1. If you have any questions, please contact Asymtek Technical
Support.
10.2 Facility Requirements
Table 10-1 Facility Requirements
Facility Requirements
System Footprint
Single Station: 600 mm x 1310 mm
Two Station: 850 mm x 1310 mm
Three Station: 1100 mm x 1310mm
Weight
Single Station: 371kg [820 lbs]
Two Station: 401kg [885 lbs]
Three Station: 431 kg [950 lbs]
Air Supply
689 kPa (6.8 atm, 100 psi), 3 CFM @ 100 psi (28 liters/hr = 3 SCFM) May
be higher depending upon application.
Main Power Supply 180 - 264 VAC, 47-63 Hz, Single Phase
Current Consumption 6A max (standard configuration)
Ambient Air Temperature
5-50 ℃
Relative Humidity < 90% non condensing
Altitude 1609 meters
Minimum Ventilation Rate 100 cfm
10.2.1 System Dimensions
Detailed system dimensions are shown in the diagram listed in 3HTable 10-2. A laminated copy is included
with the dispensing system.
Table 10-2 System Dimensions Diagram
Drawing Number Title
7210740 S-920 Facility Specification
