ID50 Series Panel - Installation, Commissioning & Configuration Manual
Configuration Mode
56997-263, Issue 4
October 2002
5.6.1.4AUX Action
An input device assigned to zones 17 to 32 is treated as
a Plant alarm input and given the default type of AUX.
The auxiliary action specifies which of the following
actions takes place with the operation of an AUX input:
i Plant Alarm - non-latching
ii Panel Reset
iii Silence Sounders
iv Mute Buzzer
v Class Change
vi Abort Switch - latching
vii Hold switch - non-latching
To ensure recognition by the panel, the input device must
be active for at least 5 seconds (longer if not priority-
polled).
To select the required auxiliary action:
1 Using the numeric keypad, press
3
at the module
edit screen to select the auxiliary Action option (the
default action is PLANT).
2 The screen displays action options as follows:
Press the
2
/
8
buttons to display other AUX action
options, as appropriate.
3 Press the appropriate numeric pushbutton to select
the required action, e.g. Abort Switch. The display
confirms the selection and returns to the module edit
screen:
Press the
4
button to exit the module edit screen.
[Module nn - AUX] 1: Zone (17) 2: CBE Rule (nn)
3: Action (PLANT) 4:[ Blank/Existing Text ]
[Module nn - AUX] 4: Mute Buzzer
5: Class Change 6: Abort Switch × : More
[Module nn - AUX] 1: Plant Alarm
2: Reset Panel 3: Silence Sounders × : More
[Module nn - AUX] 7: Hold Switch
× : More
[Module nn - AUX] 1: Zone (17) 2: CBE Rule (nn)
3: Action (ABORT) 4:[ Blank/Existing Text ]
The first 30 modules (from
lowest address upwards)
restricted to types MCP, DKM,
MRL, IRL and all AUX actions
except Plant Alarm, are added
automatically to a priority poll
list. Subsequent modules are
polled normally.
