Notifier

ID50 - Two Zone

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Configuration Mode
69 997-263, Issue 4
September 2002
5.7.7 Two Zone
The Two Zone option has two states, Yes (Y) and No (N).
This option is available with the Fire, Pre-Alarm and Plant
Warning rules. To change the Two Zone rule setting:
1 Press the 
7
 button (using the numeric keypad) to
select the pattern Two Zone option from the menu
below.
2 Press the 
6
 button to select the required setting.
Refer to Section5.7, Control-By-Event Output
Rules for further information.
3 Confirm the selection by pressing the 
5
 button. To
cancel the selection, press 
4
. In either case the
menu below is re-displayed.
CBE Rule:01 6:Class Change 7:Two Zone
9:Zones × : More
CBE Rule:01 Two Zone = [N]
>:Change 3:Accept < : Cancel
CBE Rule:01 Two Zone = [Y]
>:Change 3:Accept < : Cancel
CBE Rule:01 6:Class Change 7:Two Zone
9:Zones × : More
6
5
7
