ID50 Series Panel - Installation, Commissioning & Configuration Manual
Appendix 1 - Specifications
A1 - 2997-263, Issue 4
September 2002
Environmental:
Climatic classification: 3K5, (IEC 721-2-3)
Operating temperature: -5
o
C to +45
o
C,
(recommended +5
o
C to 35
o
C)
Humidity: 5% to 95% R.H.
Height above sea level: Maximum, 2000m
Panel sealing: IP30, (EN60529)
Vibration: EN60068-2-6, 10-150Hz at
0.981ms
-2
(Meets the requirements
of EN54-2/4)
EMC: Emissions: EN50081-1
Immunity: EN50130-4
Safety: EN60950
Displays and Indications:
Alphanumeric display: 2 line x 40 character, backlit LCD.
LED Status Indicators: DISABLEMENT, TEST, BUZZER
MUTED, PLANT ALARM, DELAYED
MODE, RELAY DISABLE, POWER,
FAULT, POWER SUPPLY FAULT,
EARTH FAULT, SYSTEM FAULT,
SOUNDER FAULT, SOUNDERS
DISABLED, SOUNDERS SILENCED.
Zone Indicators: Individual FIRE and Fault/Disable/
Test indicators for 16 zones.
Controls:
Dedicated flush
pushbuttons are provided
for the following functions: RESET, MUTE BUZZER, SILENCE/
RESOUND, ENDDELAYS/
EVACUATE.
Additional pushbuttons for
configuration and selection
of software functions:
2 4 6 8
KEYS
5
KEY
0..9
KEY
KEY
10 BUTTON NUMERIC KEYPAD
System Capacity:
Number of loops: 1
Number of zones: 32 (16 Fire + 16 Plant Alarm)
Devices per loop: 99 sensors + 99 modules or
99sensors + combination of up
to99 modules/sounders within
strict limits.
