Characteristics
Position Description
1 Door
2 Clean demineralized water tank input
3 Operator panel
4 Front USB port
5 Main switch
6 Printer (optional)
7 Handle
8 Steel sterilizing chamber closure disc
9 Sterilization chamber
10 Safety valve connection
11 Pressure sensor
12 Temperature sensor
13 Tray Holder
14 Locking Electromagnet
15 Drain Filter
16 Water drain connection
17 Water drain selector
18 Bacteriological filter
19 Condenser
20 Clean water load external connection
21 Used water drain external connection
22 Overflow drain connections
23 Sterilization chamber maximum pressure safety valve
24 Ethernet port (LAN)
25 Rear USB port (not usable for firmware update).
26 Power outlet
27 AUX port
28 Electrical protection fuses
