Maintenance
29 VACUUM PUMP R604011 R604011
30 DRAINAGE SELECTOR ASSEMBLY R153009 R153009
31 CHAMBER ASSEMBLY R153002 R153001
32 TRAY HOLDER R716003 R716002
33 NARROW TRAY R716030 R716028
34 WIDE TRAY R716029 R716027
35 NETWORK FILTER R020185 R020185
36 SAFETY VALVE R220005 R220005
37 CHAMBER FILTER R105320 R105320
38 EU POWER CORD (SHUKO PLUG) R607003 R607003
39 UK POWER CORD (UK PLUG) R607005 R607005
40 GASKET DOOR R716055 R716055
41 BACTERIOLOGICAL FILTER 021008 021008
42 TANK H20 FILTER R200919 R200919
7.7 Hot and cold spot inside the chamber
The highlighted points in the photo show the areas within the chamber with the highest and lowest temperatures
on average during normal operation.
The red dot is the maximum temperature and the blue dot is the minimum temperature.
