Mouse: Click in the respective item
Select the items to set.
X (Mouse: Left Click X or Right Click to leave)
Press this button to escape from this screen, and return to Setup Menu display. If the
contents have been modified, a Save dialog will be shown to ask the user to save the
changes, press YES to exit and save, CANCER to exit without saving.
HDD Format/Clear (Mouse: Left click)
Press this button to format/clear the HDDs as described in Section 6.5.1.
Advanced HDD Setup (Mouse: Left click)
Press this button to enter Advanced HDD Setup as described in Section 6.5.2.
Following is a brief description for each item and its specific operations:
Size (GB) – the total HDD storage in GB (Giga-Byte) for Alarm Record and Normal
Record respectively. This item is just for information. Please refer to Section 6.5.1 for
more detailed information and the setup of each HDD. Please note that if the total
alarm record size is zero, the alarm video/audio will be recorded in the normal record
partition. If the total normal record size is zero, the normal video/audio will be
recorded in the alarm record partition.
Auto Overwrite – automatic overwrite of the recorded video/audio from HDD#1
when the Alarm/Normal Record disk drive capacity reaches the end of the last HDD.
If Auto Overwrite is disabled and the Alarm/Normal Record disk drive capacity
reaches the end, the system will not overwrite the recorded video/audio, and hence
not record Alarm/Normal video/audio, until the user presses the Alarm Reset button.
HDD Full Action – actions when Alarm/Normal Record disk drive capacity reaches the
end of the last HDD.
Duration – response duration to define at most how long (in seconds) the Alarm Out
relay and the Buzzer will keep being triggered after the corresponding partition,
Alarm Record or Normal Record, is full. The value - means forever.
Alarm Out – to define which Alarm Output will be triggered when this event is
triggered. Alarm Output Source Setup up to 32 alarm outputs can be selected and the
definitions are similar to alarm inputs.
Buzzer – to activate the internal Buzzer or not when the corresponding partition,
Alarm Record or Normal Record, is full.
Log – to log to event logs or not.
E-mail – to send the event e-mail to remote station or not. The e-mail will be sent to
the predefined receivers when the event is triggered.
