- 82 -
corresponding camera and live/playback mode. The user may click on the “Print”
button to print the video to the printer, or “Snapshot” the video. The user may also
double click for 1-Window display.
Click on these icons for 1/4/9/16/25/36/49/64-Window display. For 4/9 split windows,
the user can click on the icon, and select a different display page.
Click on this icon to switch to or return from SEQ display mode.
Click on this icon to toggle between live mode and playback mode for all the video
windows.
Click on this icon to freeze/unfreeze the video images for all the video windows.
Click on this icon to enable/mute the audio input from the PC, button down for
enable, button up for mute. If enabled, the audio input from the PC will be sent to the
DVR. The default setting is ‘mute’.
Click on this icon to enable/mute the audio output from the camera for the focus
window (or DVR), button down for enable, button up for mute.
Click on this icon to show/hide the GPS data for (1) the selected DVR, or (2) the DVR
for the focus camera, button down to show, button up to hide.
Click on this icon to show/hide the POS data (for 9-split-window or larger video
window) for (1) the selected DVR, or (2) the DVR for the focus camera, button down
to show, button up to hide.
