- 86 -
Following is a brief description for each item:
Device Name – any meaningful name for the (DVR) device.
Address – IP address or URL domain name for the (DVR) device. It should be the
same as the IP address (for Static IP) or URL (for PPPoE) in Network Setup for the
(DVR) device.
Control Port – the control port for the (DVR) device. The default value is 67.
Data Port – the data port for the (DVR) device. The default value is 68.
Video Stream – “Record” – live video same as recording stream, or “Extra” – extra
network stream if dual streaming is supported for the (DVR) device. The default
value is “Record”.
User Name – the login user name for the (DVR) device. It must be in the list in
Password Setup for the (DVR) device. Please note that different levels of users
have different available operations.
Password – the corresponding password for the login user name for the (DVR)
device.
Auto Connection – whether the user wants to connect automatically to this (DVR)
device.
Connected – whether this PC is connected with the (DVR) device now. If a DVR
is connected, the user may select it, and click on “Reboot” to reboot it.
The user can download/upload the configurations from/to the connected DVR, or
open/save the configurations from/to the designated directory.
Click on this icon to call up remote Software Upgrade dialog. The current software
version of the DVR(s) will be shown in the “status” field. Please select the DVR device
and upgrade file in the PC, and then click on Start button to start the software
upgrade process. The Upgrade status will be updated according to the progress.
When the upgrade file is uploading, the user may click on Stop/Close button to stop
the upgrade process.After the software in the DVR is upgraded, the DVR will restart
immediately and the PC will be disconnected from the DVR.
Note: There must be at least one formatted HDD in the DVR for the remote upgrade
to succeed.
Click on this icon to call up GPS Configuration dialog. Please select the DVR device.
Then select Displayattributes and Outputattributes for Live&Playback respectively.
