NXP Semiconductors MPC5777M - Page 95

Electrical characteristics
MPC5777M Microcontroller Data Sheet, Rev. 6
NXP Semiconductors 95
10 t
HO
CC SOUT data hold
time after SCK
10
SOUT and SCK drive strength
Very strong 25 pF –7.7 — ns
Strong 50 pF –11.0 —
Medium 50 pF –15.0 —
1
All output timing is worst case and includes the mismatching of rise and fall times of the output pads.
2
All timing values for output signals in this table are measured to 50% of the output voltage.
3
Timing is guaranteed to same drive capabilities for all signals, mixing of pad drives may reduce operating speeds
and may cause incorrect operation.
4
N is the number of clock cycles added to time between PCS assertion and SCK assertion and is software
programmable using DSPI_CTARx[PSSCK] and DSPI_CTARx[CSSCK]. The minimum value is 2 cycles unless
TSB mode or Continuous SCK clock mode is selected, in which case, N is automatically set to 0 clock cycles (PCS
and SCK are driven by the same edge of DSPI_CLKn).
5
t
SYS
is the period of DSPI_CLKn clock, the input clock to the DSPI module. Maximum frequency is 100 MHz (min
t
SYS
=10ns).
6
M is the number of clock cycles added to time between SCK negation and PCS negation and is software
programmable using DSPI_CTARx[PASC] and DSPI_CTARx[ASC]. The minimum value is 2 cycles unless TSB
mode or Continuous SCK clock mode is selected, in which case, M is automatically set to 0 clock cycles (PCS and
SCK are driven by the same edge of DSPI_CLKn).
7
t
SDC
is only valid for even divide ratios. For odd divide ratios the fundamental duty cycle is not 50:50. For these odd
divide ratios cases, the absolute spec number is applied as jitter/uncertainty to the nominal high time and low time.
8
PCSx and PCSS using same pad configuration.
9
Input timing assumes an input slew rate of 1 ns (10% – 90%) and uses TTL / Automotive voltage thresholds.
10
SOUT Data Valid and Data hold are independent of load capacitance if SCK and SOUT load capacitances are the
same value.
Table 51. DSPI CMOS master classic timing (full duplex and output only) – MTFE = 0, CPHA = 0 or 1
1
# Symbol Characteristic
Condition Value
2
Unit
Pad drive
3
Load (C
L
)Min Max
