Oki MB770dn User Manual

SETTING ITEMS (ADMIN)
- 285 -
2
1
3
4
5
6
7
Memo
• When you press [USER NAME], [NEW PASSWORD]
or [RETYPE NEW PASSWORD], the on-screen
keyboard is displayed.
For details of the on-screen keyboard, see the
following page:
 P.300 "On-screen keyboard"
• The input password appears as asterisks (*) in the
[NEW PASSWORD] and [RETYPE NEW PASSWORD]
boxes.
802.1X SETTINGS
You can make settings for IEEE 802.1X authentication that will
apply to wired networks.
This equipment supports the following authentication methods:
• EAP-MSCHAPv2
• EAP-MD5
• EAP-TLS
• PEAP
*1
The following protocols are available for inner
authentication:
- EAP-MSCHAPv2
• EAP-TTLS
The following protocols are available for inner
authentication:
-PAP
- CHAP
- EAP-MSCHAPv2
- EAP-MD5
*1 PEAP cannot be used for Windows Server 2008.
To enable IEEE 802.1X authentication, you must install
certificates in this equipment as required, using TopAccess.
The certificates that must be installed are as follows.
*1 The CA certificate must be installed in this equipment before the
settings for IEEE 802.1X authentication are performed.
*2 The user certificate must be installed in this equipment before the
settings for IEEE 802.1X authentication are performed.
Memo
• For instructions on how to install certificates, refer to the
TopAccess Guide “Chapter 8: [Administration] Tab
Page”.
• For instructions on how to display the WIRED 802.1X
SETTINGS screen, see the following page:
 P.232 "Accessing the Admin Menu"
Setting IEEE 802.1X authentication
1
On the WIRED 802.1X SETTINGS screen,
specify the following items as required and
press [NEXT].
Authenticatio
n Method
Inner
Authenticatio
n Method
CA
Certificate
User
Certificate
EAP-
MSCHAPv2
---
EAP-MD5 - - -
EAP-TLS -
Necessary
*1
Necessary
*2
PEAP EAP-
MSCHAPv2
Necessary
*1
-
EAP-TTLS PAP
Necessary
*1
-
CHAP
Necessary
*1
-
EAP-MD5
Necessary
*1
-
EAP-
MSCHAPv2
Necessary
*1
-
Item name Description
802.1X • ENABLE — Press this button
to use IEEE 802.1X
authentication.
• DISABLE — Press this button
to disable IEEE 802.1X
authentication.
Memo
• When changing
IEEE802.1X authentication
from [ENABLE] to
[DISABLE], press [Next],
and on the “Confirm the
following settings” screen
that appears, press [APPLY
NOW] to complete the
setting.
CHECK
SETTINGS
Press this button to confirm the
options currently selected.
Note
• [CHECK SETTINGS] is
available when you selected
[ENABLE] for 802.1X.
FACTORY
DEFAULT
Press this button to reset the
IEEE802.1X settings back to the
factory defaults.
