EDITING FUNCTIONS
- 83 -
2
1
3
4
5
6
7
Image Editing
You can select the various editing functions shown below for
scanned images.
Trimming: You can select a certain area of an original and
copy only the selected area.
Masking: You can mask a certain area of an original and
copy only the unmasked area.
Mirror image: You can reverse an image like a mirror.
Negative/Positive reversal: You can reverse the light-and-
dark of an image.
Trimming / Masking
You can select the desired area of an original and copy only
the selected area (trimming). You can also mask the desired
area of an original and copy only the unmasked area
(masking). On both functions you can select up to 4 areas on 1
original. The selected area should be in a rectangle.
Memo
• Only standard size originals are applicable.
• Note that the entire image of the selected area may not be
copied if you do not select proper sizes for the original and
copy paper.
1
Place paper in the tray(s).
When using bypass copying, be sure to set the paper
size.
2
Press [EDITING] on the EDIT menu.
3
Select [TRIM] or [MASK].
4
Place the original on the document glass
with its face up.
Place it with its bottom toward you. Align its top left corner
against that of the document glass so that the original will
be aligned with the original scales.
Do not place any heavy objects (4 kg (9 lb.) or over)
on the document glass and do not press on it with
force.
Breaking the glass could injure you.
Trimming Masking
