44473001TH Rev.1
222 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
(6) Hold jammed paper by the top edge, and gently pull it out.
If the top edge of the paper cannot be seen, slowly pull out the paper with by the
bottom edge.
(7) Hold the blue handles of the image drum unit with both hands and place it into the
MFP.
(8) Close the top cover and scanner unit.
Error Code 381, 382, 385
(1) Remove any documents from the document tray.
(2) Open the scanner unit.
(3) Press the top cover open button and open the top cover.
Important To
uch any screw inside the MFP to remove static electricity from your
body.
(4
) Hold the blue handles of the image drum unit with both hands and lift it out of the
MFP, and then place it on a flat surface.
Co
ver the image drum unit with black paper or a black bag.
To Next Page
