DMTA-20006-01EN, Rev. B, February 2014
Accessories and Spare Parts 53
7.5CCEV35-A15-P-2.5-OM U8330826
7.5 MHz low profile phased array
probe with 16 elements, 0.5 mm
pitch, and 10 mm elevation.
The elements are curved on the
elevation with a 35 mm radius.
The cable is 2.5 m long with
OmniScan connector.
(×2)
10CCEV35-A15-P-2.5-OM U8331014
10 MHz low profile phased array
probe with 32 elements, 0.3 mm
pitch, and 7 mm elevation.
The elements are curved on the
elevation with a 35 mm radius.
The cable is 2.5 m long with
OmniScan connector.
COBRA-A-SA15 U8721205
Two flat shear wave (SW) wedges
plus ten pairs of curved shear
wave (SW) wedges to cover the
21.3 mm to 114.3 mm (0.84 in. to
4.50 in.) pipe outside-diameter
range.

COBRA-A-SA15LW U8722168
Two flat longitudinal wave (LW)
wedges plus ten pairs of curved
longitudinal wave (LW) wedges to
cover the 21.3 mm to 114.3 mm
(0.84 in. to 4.50 in.) pipe outside-
diameter range.
COBRA-A-ST1-70L U8701348
Two flat wedges plus nine pairs of
curved time-of-flight diffraction
(TOFD) wedges to cover the
26.7 mm to 114.3 mm (1.05 in. to
4.50 in.) pipe outside-diameter
range. Compatible with 3 mm
diameter element ST1 UT probes.
COBRA-SP-IRRIGATION U8775226
Spare parts kit including irrigation
tubes, fittings, and valve (see
Table 8 on page 57)
COBRA-SP-BASIC U8775166
Basic spare parts kit (see
Figure 4-2 on page 57)
Table 6 COBRA Scanner ordering part numbers (continued)
Part number Item number Description
Package
COBRA-K-4.5
