ZUIKO DIGITAL interchangeable lenses
13
Accessories
Nomenclature
1 Rear cap
2 Filter mount thread
3 Zoom ring
4 Focus ring
5 Mount index
6 Electrical contacts
7 Front cap
Main Specifications
Mount : Four Thirds Mount
Focal distance : 17.5 - 45mm
Max. aperture : f3.5 - 5.6
Image angle :63° - 27°
Lens configuration : 7 groups, 7 lenses
Iris control :f3.5 - f22
Shooting range : 0.28m (1.2ft) - ∞ (infinite)
Focus adjustment : AF/MF switching
Weight : 210g (7.4oz) (excluding cap)
Dimensions : Max. dia. φ 71 x Overall length 70.0 mm (2.8in)
Filter mount thread diameter
:52mm
1
234
5
6
7
Hold down the exterior part
of the filter mount thread
when mounting the filter on
the lens.
