8. Command and Response Structure
COMMAND SUFFIX ITEM AFFECTED # CHAR SECTION
G,P,R,W 10 SP.CNF, control setpoints 1 and 2 2 10.5
G,P,R,W 11 AL.CNF, control setpoints 3 and 4 2 10.6
G,P,R,W 12 AL MOdE, alarm function 2 10.7
G,P,R,W 13 NUM.dLy, alarm delay 2 10.8
R,W 14 SP db, setpoint hysteresis 4 10.36
R,W 15 AL db, alarm hysteresis 4 10.37
G,P,R,W 16 OUt.CNF, analog out and Ad.RAtE 2 10.9
G,P,R,W 17 OUt SC, analog out scale 6 10.34
R,W 18 COMM, communications config 2 10.11
G,P,R,W 1A AddRES, RS-485 device # address 2 10.29
G,P,R,W 1B dAt.FMt, communication data format 2 10.12
G,P,R,W 1C bUS.FMt, communications BUS format 2 10.13
R,W 1D SERCNt, # of readings between transmissions 4 10.30
G,P,R,W 1E SER.RCG, recognition character 2 10.31
G,P,R,W 1F SER.UOM, units of measure 6 10.32
R,W 20 SER.dLy, communication turnaround delay 2 10.33
G,P,R,W 21 SP 1, setpoint 1 value 6 10.28
G,P,R,W 22 SP 2, setpoint 2 value 6 10.28
G,P,R,W 23 SP 3, setpoint 3 value 6 10.28
G,P,R,W 24 SP 4, setpoint 4 value 6 10.28
G,P,R,W 25 INP OF, input offset 6 10.35
G,P,R,W 26 OUt OF, analog output offset 6 10.35
G,P,R,W 40 RAM or EEPROM BLOCK A 60 10.17
G,P,R,W 41 RAM or EEPROM BLOCK B 38 10.18
R,W 42 EEPROM BLOCK C 20 10.19
R,W 43 EEPROM BLOCK D - 10.20
R,W 44 EEPROM BLOCK E - 10.21
R,W 45 EEPROM BLOCK F - 10.22
R,W 49 Analog Output Option Board (AN03) Calibration 16 --
R,W 50 1st two bytes for “Set Color Config, 2nd two bytes
for “NUM.PNt” value of Multi-point Scale & Offset 2 10.26
R,W 51 Multi-point Scale & Offset Input / Read 0 values 6 10.27
R,W 52 Multi-point Scale & Offset Input / Read 1 values 6 10.27
R,W 53 Multi-point Scale & Offset Input / Read 2 values 6 10.27
R,W 54 Multi-point Scale & Offset Input / Read 3 values 6 10.27
R,W 55 Multi-point Scale & Offset Input / Read 4 values 6 10.27
R,W 56 Multi-point Scale & Offset Input / Read 5 values 6 10.27
R,W 57 Multi-point Scale & Offset Input / Read 6 values 6 10.27
R,W 58 Multi-point Scale & Offset Input / Read 7 values 6 10.27
R,W 59 Multi-point Scale & Offset Input / Read 8 values 6 10.27
R,W 5A Multi-point Scale & Offset Input / Read 9 values 6 10.27
