10. Data Format Commands (P, G, R, W)
10.5 SETPOINT 1 AND 2 CONFIGURATION (“SP.CNF”)
Table 10.5 Setpoint Configuration
BIT POSITION SP.CNF
76543210
0 AbOVE SP1 Active Above
1 bELOW SP1 Active Below
0 N.OPEN SP1 Normal Open
1 N.CLOSE SP1 Normal Close
0 SP1 Use Un-filtered Value
1 SP1 Use Filtered Value
0 AbOVE SP2 Active Above
1 bELOW SP2 Active Below
0 N.OPEN SP2 Normal Open
1 N.CLOSE SP2 Normal Close
0 SP2 Use Un-filtered Value
1 SP2 Use Filtered Value
0 SP1 & SP2 Enable
1 SP1 & SP2 Disable
0 LED1 & 2 Enable
1 LED1 & 2 Disable
EXAMPLE: Set Setpoint 1 (SP1) active above, Relay 1 at normal close, Setpoint 2
(SP2) active below, Relay 2 at normal open, enable SP1 and SP2’s function, and
LED’s light up when input signal filtered value reaches the Setpoint 1 and 2:
The command data is 00101110BIN. = 2E HEX. Then send *W102E
