10. Data Format Commands (P, G, R, W)
10.17 BLOCK A
BLOCK COMMAND PREFIX COMMAND SUFFIX (HEX)
A R,W 40
NOTE: R,W means “R” or “W”
This block consists of ten (10) items and thirty bytes (60 ASCII characters):
TABLE 10.17 R/W40 (BLOCK A)
*W40200000100001200000100001200000100001200000200000200000200000
HEX BYTE NUMBER DEFAULT
COMMAND DESCRIPTION NUMBER OF VALUE
SUFFIX & ORDER BYTE
26 Analog Out Offset 1, 2, 3 3 200000
17 Analog Out Scale 4, 5, 6 3 100001
25 Input Offset 7, 8, 9 3 200000
0B Input Scale 10, 11, 12 3 100001
09 Reading Display Offset 13, 14, 15 3 200000
08 Reading Display Scale 16, 17, 18 3 100001
24 Setpoint 4 Value 19, 20, 21 3 200000
23 Setpoint 3 Value 22, 23, 24 3 200000
22 Setpoint 2 Value 25, 26, 27 3 200000
21 Setpoint 1 Value 28, 29, 30 3 200000
