10-5
10. Data Format Commands (P, G, R, W)
10.4
FILTER CONFIGURATION “FILtER” AND “
OUt.tyP”
TABLE 10.4 FILTER CONFIGURATION and OUTPUT TYPE
BIT POSITION FILtER and OUt.tyP
76543210
000001 Filter Time 1
001002 Filter Time 2
010004 Filter Time 4
011008 Filter Time 8
100016 Filter Time 16
101032 Filter Time 32
110064 Filter Time 64
111128 Filter Time 128
X (Not Used)
0 A.b.C.FIL ABC Filter Type
1 MOV.AVE Moving Average Filter Type
1 FILtRd Filtered Value on the Display
00 UNFILt Unfiltered Value to Analog Output
01 FILtRd Filtered Value to Analog Output
10 PEAk Value to Analog Output
11 VALLy Value to Analog Output
EXAMPLE: To set the meter’s display with a rapid changing input signal the filter time
constant should be higher (for example FILt.tM = 32), switch Filter Type to MOV.AVE,
and set Output Type to be filtered:
The command data is 01110101BIN. = 75 HEX. Then send *W0E75
