10. Data Format Commands (P, G, R, W)
10.16 COLOR CONFIGURATION (“COLOR”)
TABLE 10.16 COLOR CONFIGURATION
BIT POSITION COLOR
76543210
0 0 SP1 COLOR: HOLD
0 1 SP1 COLOR: GREEN
1 0 SP1 COLOR: RED
1 1 SP1 COLOR: AMBER
0 0 SP2 COLOR: HOLD
0 1 SP2 COLOR: GREEN
1 0 SP2 COLOR: RED
1 1 SP2 COLOR: AMBER
0 0 AL1 COLOR: HOLD
0 1 AL1 COLOR: GREEN
1 0 AL1 COLOR: RED
1 1 AL1 COLOR: AMBER
0 0 AL2 COLOR: HOLD
0 1 AL2 COLOR: GREEN
1 0 AL2 COLOR: RED
1 1 AL2 COLOR: AMBER
EXAMPLE: To setup LED’s display change color to RED then AMBER when reading
reaches SP1 value then AL1 (SP3) value respectively, but hold the color for SP2 or
AL2:
The command data is 00110010 BIN. = 32 HEX. Then send *W0332
