10-23
10. Data Format Commands (P, G, R, W)
10.21 R/W44 (BLOCK E)
To write default value:
W44800000008000000080000000800000008000000080000000
TABLE 10.21 R/W44 (BLOCK E)
BYTE NUMBER DESCRIPTION NUMBER OF DEFAULT
& ORDER BYTE VALUE
1,2 500mV Scale 2 8000
3,4 500mV Offset 2 0000
5,6 5 V Scale 2 8000
7,8 5 V Offset 2 0000
9,10 50V Scale 2 8000
11,12 50V Offset 2 0000
13,14 1 V Scale 2 8000
15,16 1 V Offset 2 0000
17,18 10 V Scale 2 8000
19,20 10 V Offset 2 0000
21,22 100 V Scale 2 8000
23,24 100 V Offset 2 0000
10.22 R/W45 (BLOCK F)
To write default value: W450000
TABLE 10.22 R/W45 (BLOCK F)
BYTE NUMBER DESCRIPTION NUMBER OF DEFAULT
& ORDER VALUE
1,2 Cal. Quasi Offset 2 0000
10.23 R46
This command is for the channel one of A/D.
10.24 R47
This command is for the channel two of A/D
10.25 R48
This command is for the channel three of A/D
