8.6 STATUS CHARACTER FORMATS
The meter upon receiving U01 or U02 Command will transmit alarm or peak/valley
status characters respectively.
8.6.1 ALARM STATUS CHARACTERS
Table 8.4 shows the transmitted character for each of the sixteen possible
setpoint/alarm states. (Note the binary progression.)
Table 8.4. Alarm Status Characters
CHARACTER SP#4 SP#3 SP#2 SP#1
@ OFF OFF OFF OFF
A OFF OFF OFF ON
B OFF OFF ON OFF
C OFF OFF ON ON
D OFF ON OFF OFF
E OFF ON OFF ON
F OFF ON ON OFF
G OFF ON ON ON
H ON OFF OFF OFF
I ON OFF OFF ON
J ON OFF ON OFF
K ON OFF ON ON
L ON ON OFF OFF
M ON ON OFF ON
N ON ON ON OFF
OONONONON
