10. Data Format Commands (P, G, R, W)

10.14 LOCKOUT CONFIGURATION (“LCk.CNF”)

TABLE 10.14 LOCKOUT CONFIGURATION

BIT POSITION LCk.CNF

76543210

0 SP1 LOCKOUT: UNLOCK

1 LOCK

0 SP2 LOCKOUT: UNLOCK

1 LOCK

0 AL1 LOCKOUT: UNLOCK

1 LOCK

0 AL2 LOCKOUT: UNLOCK

1 LOCK

0 INPUt LOCKOUT: UNLOCK

1 LOCK

0 RdG.CFG LOCKOUT: UNLOCK

1 LOCK

0 INP.CFG LOCKOUT: UNLOCK

1 LOCK

0 MP.SC.OF LOCKOUT: UNLOCK

1 LOCK

EXAMPLE: To prevent unauthorized modification of Setpoint 1 (SP1), Input type,

Reading Configuration menu and Multi-Point Scale and Offset menu:

The command data is 10110001 BIN. = 14 HEX. Then send *W01B1
