10-18
10. Data Format Commands (P, G, R, W)
10.17 BLOCK A continued
EXAMPLE: To configure meter working with the following order and desired options:
FUNCTIONS DESIRED OPTIONS EQUIVALENT
HEX VALUE
Analog Out Offset 0 700000
Analog Out Scale 0.0001 A186A0
Input Offset 0 700000
Input Scale 1 6186A0
Display Offset 0 700000
Display Scale 1 6186A0
Setpoint 4 Value +40000. 109C40
Setpoint 3 Value +30000. 107530
Setpoint 2 Value +20000. 104E20
Setpoint 1 Value +10000. 102710
The command data is in order as following:
700000A186A07000006186A07000006186A0109C40107530104E20102710
Then send:
*W40700000A186A07000006186A07000006186A0109C40107530104E20102710
