© 2011 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev F
Drawers 3-7
Pharmacy Drawer Installation
11. Install the slide support bracket with slide attached.
Figure 3-6. Install the New Slide Support Bracket
12. Place the drawer controller cable between the two ends of the drawer controller cable clamp.
13. Secure the pharmacy drawer controller cable clamp and the drawer controller cable to the
pharmacy drawer. Use the two screws provided with a Torx T10 screwdriver.
14. Close the drawer and replace the pharmacy manual override cover.
15. Power up the cabinet.
16. Program the drawer at the OmniSupplier in Omni Configurations.
Note:
The washers must be used. They ensure that the screw threads do not protrude into the cable path.
