OmniRx G4 Console Upgrade
This chapter provides detailed instructions on how to upgrade the OmniRx to the new G4
console.
Tools List
The following tools are required to install the electronics tray:

T8 Torx Driver

T10 Torx Driver

T15 Torx Driver

9/64” Allen wrench

Standard adjustable wrench

Standard pliers

Small ratchet w/ Torx T30 bit

Kapton Tape

#2036 cam lock key

#2378 cam lock key
General Shutdown
Perform shutdown procedures before doing any service.
1. Perform a graceful shutdown of the electronics sled.
2. Unplug the power cable and any network cables from the rear of the OmniRx.
3. Unlock the console with the #2036 key.
4. Lift the console lid from the rear of the OmniRx, then prop it up.
Caution:
Use an ESD wrist band while working inside the sled.
