3 - 11
3 Operation Procedure for Drive Programming
Drive Programming User’s Manual (I580-E2)
3-2 Parameters Related to Drive Programming
3
Up to 32 parameters are provided as the user parameters for the Drive Programming.
Use these parameters for various purposes such as program initial data setting, parameter for adjust-
ment, and saving calculation results.
Precautions for Correct Use
• For the data that exceeds four digits, the upper four digits of the data is displayed on the Dig-
ital Operator, as shown below.
A dot at the end of number represents the decimal point position. You can use this to figure
out the number of digits.
Display for data 0 to 9,999: 0. to 9999.
Display for data 10,000 to 65,535: 1000 to 6553
Display for data 1,230,000 and 1,230,000: 123 and 1230
• As the Digital Operator displays only upper four digits, you cannot check or set lower digits of
data.
Use the CX-Drive to check or set the data that exceeds four digits.
User Parameters of Drive Programming
Parameter
No.
Function name Data Description
P100 Drive Programming
User Parameter U00
0 to 65,535 • These user parameters correspond to
the function variables U(00) to U(28).
• You can change the data by using the
Digital Operator. The changed data is
saved in the EEPROM.
• The set data will be saved in the
EEPROM when the Write to
EEPROM command is executed in
the Drive Programming.
P101 Drive Programming
User Parameter U01
P102 Drive Programming
User Parameter U02
P103 Drive Programming
User Parameter U03
P104 Drive Programming
User Parameter U04
P105 Drive Programming
User Parameter U05
P106 Drive Programming
User Parameter U06
P107 Drive Programming
User Parameter U07
P108 Drive Programming
User Parameter U08
P109 Drive Programming
User Parameter U09
P110 Drive Programming
User Parameter U10
P111 Drive Programming
User Parameter U11
P112 Drive Programming
User Parameter U12
P113 Drive Programming
User Parameter U13
