CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-1 CJ2 CPU Unit Instruction Execution Times and Number of Steps
4
4-1-1 Sequence Input Instructions
4-1-1 Sequence Input Instructions
4-1-2 Sequence Output Instructions
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
LOAD LD 1 to 2 0.016 0.040 ---
!LD 2 to 14 0.99 1.260 ---
LOAD NOT LD NOT 1 to 2 0.016 0.040 ---
!LD NOT 2 to 14 0.99 1.260 ---
AND AND 1 to 2 0.016 0.040 ---
!AND 2 to 14 0.99 1.260 ---
AND NOT AND NOT 1 to 2 0.016 0.040 ---
!AND NOT 2 to 14 0.99 1.260 ---
OR OR 1 to 2 0.016 0.040 ---
!OR 2 to 14 0.99 1.260 ---
OR NOT OR NOT 1 to 2 0.016 0.040 ---
!OR NOT 2 to 14 0.99 1.260 ---
AND LOAD AND LD 1 0.016 0.040 ---
OR LOAD OR LD 1 0.016 0.040 ---
NOT NOT 1 0.016 0.040 ---
CONDITION ON UP 3 0.26 0.36 ---
CONDITION OFF DOWN 4 0.27 0.40 ---
LOAD BIT TEST LD TST 4 0.11 0.16 ---
LOAD BIT TEST NOT LD TSTN 4 0.11 0.16 ---
AND BIT TEST AND TST 4 0.11 0.16 ---
AND BIT TEST NOT AND TSTN 4 0.11 0.16 ---
OR BIT TEST OR TST 4 0.11 0.16 ---
OR BIT TEST NOT OR TSTN 4 0.11 0.16 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
OUTPUT OUT 1 to 2 0.016 0.040 ---
!OUT 2 to 14 0.99 1.320 ---
OUTPUT NOT OUT NOT 1 to 2 0.016 0.040 ---
!OUT NOT 2 to 14 0.99 1.320 ---
KEEP KEEP 1 to 2 0.048 0.060 ---
!KEEP 16 0.99 1.340 ---
DIFFERENTIATE UP DIFU 2 to 2 0.28 0.30 ---
DIFFERENTIATE DOWN DIFD 2 to 2 0.24 0.30 ---
SET SET 1 to 2 0.016 0.040 ---
!SET 2 to 14 0.99 1.360 ---
RESET RSET 1 to 2 0.016 0.040 ---
!RSET 2 to 14 0.99 1.360 ---
MULTIPLE BIT SET SETA 4 3.68 4.12 With 1-bit set
15.5 24.4 With 1,000-bit set
MULTIPLE BIT RESET RSTA 4 3.7 4.1 With 1-bit reset
15.5 24.4 With 1,000-bit reset
SINGLE BIT SET SETB 2 0.19 0.280 ---
!SETB 16 0.99 1.120 ---
SINGLE BIT RESET RSTB 2 0.19 0.280 ---
!RSTB 16 0.99 1.120 ---
