CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
Input Comparison Instructions
(double, unsigned)
=L 4 to 7 0.08 0.24 ---
<>L ---
<L ---
<=L ---
>L ---
>=L ---
Input Comparison Instructions
(signed)
=S 4 0.08 0.16 ---
<>S
<S
<=S
>S
>=S
Input Comparison Instructions
(double, signed)
=SL 4 to 7 0.08 0.24 ---
<>SL
<SL
<=SL
>SL
>=SL
Time Comparison Instructions =DT 4 16.300 27.9 ---
<>DT
<DT
<=DT
>DT
>=DT
COMPARE CMP 3 0.06 0.080 ---
!CMP 30 2.06 2.6 ---
DOUBLE COMPARE CMPL 3 to 5 0.064 0.120 ---
SIGNED BINARY COMPARE CPS 3 to 5 0.064 0.080 ---
!CPS 30 2.06 2.6 ---
DOUBLE SIGNED BINARY
COMPARE
CPSL 3 to 5 0.064 0.120 ---
TABLE COMPARE TCMP 4 10.3 12.5 ---
MULTIPLE COMPARE MCMP 4 15.2 20.3 ---
UNSIGNED BLOCK COM-
PAR E
BCMP 4 16.3 20.5 ---
EXPANDED BLOCK COM-
PAR E
BCMP2 4 5.0 5.1 Number of data
words: 1
217.2 278 Number of data
words: 255
AREA RANGE COMPARE ZCP 3 0.14 0.400 ---
DOUBLE AREA RANGE
COMPARE
ZCPL 3 to 5 0.14 0.640 ---
SIGNED AREA RANGE
COMPARE
ZCPS 3 0.14 0.400
DOUBLE SIGNED AREA
RANGE COMPARE
ZCPSL 3 to 5 0.14 0.640
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
