CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-1 CJ2 CPU Unit Instruction Execution Times and Number of Steps
4
4-1-5 Comparison Instructions
4-1-5 Comparison Instructions
TEN-MS TIMER TIMH 3 0.67 0.84 ---
TIMHX 0.67 0.84
ONE-MS TIMER TMHH 3 0.67 0.84 ---
TMHHX 0.67 0.84
TENTH-MS TIMER TIMU 3 0.67 0.84 ---
TIMUX 0.67 0.84
HUNDREDTH-MS TIMER TMUH 3 0.67 0.84 ---
TMUHX 0.67 0.84
ACCUMULATIVE TIMER TTIM 3 9.2 12.1 ---
6.9 8.4 When resetting
5.0 6.5 When interlocking
TTIMX 3 8.8 11.7 ---
6.8 8.5 When resetting
5.0 6.5 When interlocking
LONG TIMER TIML 4 to 5 5.8 7.0 ---
3.9 4.1 When interlocking
TIMLX 4 to 5 5.7 7.0 ---
3.6 3.7 When interlocking
MULTI-OUTPUT TIMER MTIM 4 6.4 7.2 ---
3.7 4.3 When resetting
MTIMX 4 5.5 6.4 ---
3.4 3.8 When resetting
TIMER RESET TRSET 2 0.58 0.8 ---
COUNTER CNT 3 0.51 0.58 ---
CNTX 0.51 0.58
REVERSIBLE COUNTER CNTR 3 9.1 11.8 ---
CNTRX 8.0 10.3
RESET TIMER/COUNTER CNR 3 4.8 5.4 When resetting 1
word
2839 2555 When resetting
1,000 words
CNRX 3 4.7 5.5 When resetting 1
word
2839 2555 When resetting
1,000 words
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
Input Comparison Instructions
(unsigned)
= 4 0.08 0.16 ---
<>
<
<=
>
>=
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
