4. Instruction Execution Times and Number of Steps
4-1 CJ2 CPU Unit Instruction Execution Times and Number of Steps
4
4-1-14 Double-precision Floating-point Instructions
4-1-14 Double-precision Floating-point Instructions
EXPONENTIAL POWER PWR 4 to 6 35.7 56.6 ---
Floating Symbol Comparison =F 4 to 6 0.13 0.26 ---
<>F
<F
<=F
>F
>=F
FLOATING- POINT TO ASCII FSTR 4 to 5 15.6 23.9 ---
ASCII TO FLOATING-POINT FVAL 3 21.2 31.4 ---
MOVE FLOATING-POINT
(SINGLE)
MOVF 3 to 4 0.18 0.20 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
DOUBLE SYMBOL COM-
PAR ISO N
=D 4 5.1 6.7 ---
<>D
<D
<=D
>D
>=D
DOUBLE FLOATING TO 16-
BIT BINARY
FIXD 3 5.1 5.4 ---
DOUBLE FLOATING TO 32-
BIT BINARY
FIXLD 3 5.1 5.4 ---
16-BIT BINARY TO DOUBLE
FLOATING
DBL 3 3.5 4.3 ---
32-BIT BINARY TO DOUBLE
FLOATING
DBLL 3 3.5 4.3 ---
DOUBLE FLOATING-POINT
ADD
+D 4 6.0 7.1 ---
DOUBLE FLOATING-POINT
SUBTRACT
−D 4 6.1 7.1 ---
DOUBLE FLOATING-POINT
MULTIPLY
*D 4 6.1 7.1 ---
DOUBLE FLOATING-POINT
DIVIDE
/D 4 6.4 7.5 ---
DOUBLE DEGREES TO
RADIANS
RADD 3 6.1 6.5 ---
DOUBLE RADIANS TO
DEGREES
DEGD 3 6.0 6.4 ---
DOUBLE SINE SIND 3 14.7 21.5 0° specified
20.4 35.4 45° specified
18.5 35.0 90° specified
DOUBLE COSINE COSD 3 14.1 20.6 0° specified
19.6 29.9 45° specified
19.1 29.8 90° specified
DOUBLE TANGENT TAND 3 7.3 9.4 0° specified
27.4 50.3 45° specified
DOUBLE ARC SINE ASIND 3 7.5 9.8 0° specified
55.0 75.2 45° specified
6.1 8.3 90° specified
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
