1158
CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-1-15 Table Data Processing Instructions
DOUBLE ARC COSINE ACOSD 3 8.3 10.9 0° specified
55.9 72.8 45° specified
43.7 72.8 90° specified
DOUBLE ARC TANGENT ATAND 3 6.1 7.4 0° specified
29.7 36.5 45° specified
DOUBLE SQUARE ROOT SQRTD 3 16.6 23.4 ---
DOUBLE EXPONENT EXPD 3 39.7 58.4 ---
DOUBLE LOGARITHM LOGD 3 35.5 52.2 ---
DOUBLE EXPONENTIAL
POWER
PWRD 4 66 99 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
SET STACK SSET 3 7.6 9.4 Designating 5 words
in stack area
107 65 Designating 1,000
words in stack area
PUSH ONTO STACK PUSH 3 4.9 5.9 ---
FIRST IN FIRST OUT FIFO 3 4.8 5.0 Designating 5 words
in stack area
231 167 Designating 1,000
words in stack area
LAST IN FIRST OUT LIFO 3 5.3 7.1 ---
DIMENSION RECORD
TABLE
DIM 5 11.1 19.7 ---
SET RECORD LOCATION SETR 4 3.8 5.5 ---
GET RECORD NUMBER GETR 4 4.6 7.9 ---
DATA SEARCH SRCH 4 13.9 25.0 Searching for 1 word
1940 3257 Searching for 1,000
words
*1
SWAP BYTES SWAP 3 10.1 17.5 Swapping 1 word
1421 2098 Swapping 1,000
words
*1
FIND MAXIMUM MAX 4 to 5 4.8 5.8 Number of values
being searched: 1
465 672 Number of values
being searched:
1,000
*1
DOUBLE FIND MAXIMUM MAXL 4 to 5 4.8 5.8 Number of values
being searched: 1
465 773 Number of values
being searched:
1,000
*1
FIND MAXIMUM FLOATING MAXF 4 to 5 5.2 6.5 Number of values
being searched: 1
682 1090 Number of values
being searched:
1,000
*1
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
