CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
HIGH-SPEED COUNTER PV PRV 4 --- 7.6 Reading pulse out-
put PV
--- 6.3 Reading high-speed
counter PV
--- 3.7 Reading PV of inter-
rupt input in counter
mode
--- 7.1 Reading PV in inter-
rupt input counter
mode
--- 6.3 Reading high-speed
counter status
--- 4.1 Reading PWM(891)
status
--- 17.5 Reading high-speed
counter range com-
parison results for 8
ranges
--- 34.6 Reading high-speed
counter range com-
parison results for
32 ranges
--- 4.9 Reading frequency
of high-speed
counter 0
COUNTER FREQUENCY
CONVERT
PRV2 4 --- 5.2 ---
COMPARISON TABLE LOAD CTBL 4 --- 31.7 Registering target
value table and
starting comparison
for 1 target value
--- 1528 Registering target
value table and
starting comparison
for 48 target values
--- 45.0 Registering range
table and starting
comparison for 8
ranges
--- 150.8 Registering range
table and starting
comparison for 32
ranges
--- 26.2 Only registering tar-
get value table for 1
target value
--- 1520 Only registering tar-
get value table for
48 target values
--- 41.8 Only registering
range table for 8
ranges
--- 150.0 Only registering
range table for 32
ranges
SPEED OUTPUT SPED 4 --- 23.5 Continuous mode
--- 24.6 Independent mode
SET PULSES PULS 4 --- 8.2 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
