CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-1 CJ2 CPU Unit Instruction Execution Times and Number of Steps
4
4-1-25 File Memory Instructions
4-1-25 File Memory Instructions
4-1-26 Display Instructions
4-1-27 Clock Instructions
4-1-28 Debugging Instructions
NETWORK RECEIVE 2 RECV2 5 44.5 82.8 ---
DELIVER COMMAND CMND 4 52.7 95.1 ---
DELIVER COMMAND 2 CMND2 5 53.0 98.1 ---
EXPLICIT MESSAGE SEND EXPLT 4 78 134 ---
EXPLICIT GET ATTRIBUTE EGATR 4 74 127 ---
EXPLICIT SET ATTRIBUTE ESATR 3 69 117 ---
EXPLICIT WORD READ ECHRD 4 65 110 ---
EXPLICIT WORD WRITE ECHWR 4 64 110 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
READ DATA FILE FREAD 5 217 372 In binary
WRITE DATA FILE FWRIT 5 216 366 In binary
WRITE TEXT FILE TWRIT 5 205 370 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
DISPLAY MESSAGE MSG 3 6.9 10.5 Displaying message
6.6 9.5 Deleting displayed
message
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
CALENDAR ADD CADD 4 15.6 22.5 ---
CALENDAR SUBTRACT CSUB 4 16.4 24.9 ---
HOURS TO SECONDS SEC 3 3.6 4.1 ---
SECONDS TO HOURS HMS 3 3.5 4.0 ---
CLOCK ADJUSTMENT DATE 2 29.6 53.2 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
TRACE MEMORY SAM-
PLING
TRSM 1 8.9 12.6 Sampling 1 bit and 0
words
31.6 33.1 Sampling 31 bits
and 6 words
38.8 39.2 Sampling 31 bits
and 16 words
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
