CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-2-5 Comparison Instructions
Instruction Mne-
monic
Length
(steps)
ON execution time (µs) Conditions
CJ1H
CPU6@
H-R
CJ1H
CPU6@
H
CJ1G
CPU4@
H
CJ1M
CPU12/
13/22/23
CJ1M
CPU11/
21
CJ1G
CPU4@
Input Compari-
son Instructions
(unsigned)
= 4 0.08 0.10 0.16 0.35 0.35 0.37 ---
<>
<
<=
>
>=
Input Compari-
son Instructions
(double,
unsigned)
=L 4 to 7 0.08 0.10 0.16 0.35 0.35 0.54 ---
<>L
<L
<=L
>L
>=L
Input Compari-
son Instructions
(signed)
=S 4 0.08 0.10 0.16 0.35 0.35 6.50 ---
<>S
<S
<=S
>S
>=S
Input Compari-
son Instructions
(double, signed)
=SL 4 to 7 0.08 0.10 0.16 0.35 0.35 6.50 ---
<>SL
<SL
<=SL
>SL
>=SL
Time Compari-
son Instructions
=DT 4 25.2 25.2 36.4 45.6 40.6 --- ---
<>DT
<DT
<=DT
>DT
>=DT
COMPARE CMP 3 0.032 0.04 0.04 0.10 0.10 0.29 ---
!CMP 7 42.2 42.2 42.2 45.3 45.3 42.7 ---
DOUBLE COM-
PAR E
CMPL 3 to 5 0.064 0.08 0.08 0.50 0.50 0.46 ---
SIGNED
BINARY COM-
PAR E
CPS 3 0.064 0.08 0.08 0.30 0.30 6.50 ---
!CPS 7 36.0 36.0 36.0 45.5 45.5 48.9 ---
DOUBLE
SIGNED
BINARY COM-
PAR E
CPSL 3 to 5 0.064 0.08 0.08 0.50 0.50 6.50 ---
TABLE COM-
PAR E
TCMP 4 14.0 14.0 15.2 29.77 32.13 21.9 ---
MULTIPLE
COMPARE
MCMP 4 20.5 20.5 22.8 45.80 48.67 31.2 ---
UNSIGNED
BLOCK COM-
PAR E
BCMP 4 21.5 21.5 23.7 47.93 51.67 32.6 ---
