CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3 CS-series Instruction Execution Times and Number of Steps
4
4-3-6 Data Movement Instructions
4-3-6 Data Movement Instructions
4-3-7 Data Shift Instructions
AREA RANGE COM-
PAR E
ZCP 3 5.3 5.4 --- --- ---
DOUBLE AREA
RANGE COMPARE
ZCPL 3 to 5 5.5 6.7 --- --- ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
MOVE MOV 3 0.18 0.20 0.25 0.29 ---
!MOV 7 21.56 21.60 42.61 42.65 CS Series
90.70 90.72 90.77 90.83 C200H
DOUBLE MOVE MOVL 3 to 4 0.32 0.34 0.42 0.50 ---
MOVE NOT MVN 3 0.18 0.20 0.25 0.29 ---
DOUBLE MOVE NOT MVNL 3 to 4 0.32 0.34 0.42 0.50 ---
MOVE BIT MOVB 4 0.24 0.34 7.5 7.5 ---
MOVE DIGIT MOVD 4 0.24 0.34 7.3 7.3 ---
MULTIPLE BIT
TRANSFER
XFRB 4 10.1 10.8 13.6 13.6 Transferring 1 bit
186.4 189.8 269.2 269.2 Transferring 255 bits
BLOCK TRANSFER XFER 4 0.36 0.44 11.2 11.2 Transferring 1 word
300.1 380.1 633.5 633.5 Transferring 1,000
words
BLOCK SET BSET 4 0.26 0.28 8.5 8.5 Setting 1 word
200.1 220.1 278.3 278.3 Setting 1,000 words
DATA EXCHANGE XCHG 3 0.40 0.56 0.5 0.7 ---
DOUBLE DATA
EXCHANGE
XCGL 3 to 4 0.76 1.04 0.9 1.3 ---
SINGLE WORD DIS-
TRIBUTE
DIST 4 5.1 5.4 7.0 7.0 ---
DATA COLLECT COLL 4 5.1 5.3 7.1 7.1 ---
MOVE TO REGIS-
TER
MOVR 3 0.08 0.08 0.42 0.50 ---
MOVE TIMER/
COUNTER PV TO
REGISTER
MOVRW 3 0.42 0.50 0.42 0.50 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
SHIFT
REGISTER
SFT 3 7.4 10.4 10.4 10.4 Shifting 1 word
433.2 488.0 763.1 763.1 Shifting 1,000 words
REVERSIBLE SHIFT
REGISTER
SFTR 4 6.9 7.2 9.6 9.6 Shifting 1 word
615.3 680.2 859.6 859.6 Shifting 1,000 words
ASYNCHRONOUS
SHIFT REGISTER
ASFT 4 6.2 6.4 7.7 7.7 Shifting 1 word
1220 1220 2010 2010
Shifting 1,000 words
*1
WORD SHIFT WSFT 4 4.5 4.7 7.8 7.8 Shifting 1 word
171.5 171.7 781.7 781.7 Shifting 1,000 words
ARITHMETIC SHIFT
LEFT
ASL 2 0.22 0.32 0.29 0.37 ---
DOUBLE SHIFT
LEFT
ASLL 2 0.40 0.56 0.50 0.67 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
