CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3-5 Comparison Instructions
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
Input Comparison
Instructions
(unsigned)
= 4 0.10 0.16 0.21 0.37 ---
<>
<
<=
>
>=
Input Comparison
Instructions (double,
unsigned)
=L 4 to 7 0.10 0.16 0.29 0.54 ---
<>L
<L
<=L
>L
>=L
Input Comparison
Instructions (signed)
=S 4 0.10 0.16 6.50 6.50 ---
<>S
<S
<=S
>S
>=S
Input Comparison
Instructions (double,
signed)
=SL 4 to 7 0.10 0.16 6.50 6.50 ---
<>SL
<SL
<=SL
>SL
>=SL
Time Comparison
Instructions
=DT 4 25.1 36.4 --- --- ---
<>DT 4 25.2 36.4 --- ---
<DT 4 25.2 36.4 --- ---
<=DT 4 25.2 36.4 --- ---
>DT 4 25.1 36.4 --- ---
>=DT 4 25.2 36.4 --- ---
COMPARE CMP 3 0.04 0.04 0.17 0.29 ---
!CMP 7 42.14 42.14 42.57 42.69 CS Series
90.44 90.44 90.67 90.79 CS Series
DOUBLE COMPARE CMPL 3 to 5 0.08 0.08 0.25 0.46 ---
SIGNED BINARY
COMPARE
CPS 3 0.08 0.08 6.50 6.50 ---
!CPS 7 35.98 35.98 48.9 48.9 CS Series
84.18 84.18 97.0 97.0 C200H
DOUBLE SIGNED
BINARY COMPARE
CPSL 3 to 5 0.08 0.08 6.50 6.50 ---
TABLE COMPARE TCMP 4 14.0 15.2 21.9 21.9 ---
MULTIPLE COM-
PAR E
MCMP 4 20.5 22.8 31.2 31.2 ---
UNSIGNED BLOCK
COMPARE
BCMP 4 21.5 23.7 32.6 32.6 ---
EXPANDED BLOCK
COMPARE
BCMP2 4 8.4 9.3 --- --- Number of data
words: 1
313.0 345.3 --- --- Number of data
words: 255
