CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3 CS-series Instruction Execution Times and Number of Steps
4
4-3-4 Timer and Counter Instructions
4-3-4 Timer and Counter Instructions
NEXT LOOP NEXT 1 0.17 0.17 0.17 0.17 When loop is continued
0.12 0.12 0.12 0.12 When loop is ended
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
HUNDRED-MS
TIMER
TIM 3 0.56 0.88 0.37 0.42 ---
TIMX 3 0.56 0.88 0.37 0.42 ---
TEN-MS TIMER TIMH 3 0.88 1.14 0.37 0.42 ---
TIMHX 3 0.88 1.14 0.37 0.42 ---
ONE-MS TIMER TMHH 3 0.86 1.12 0.37 0.42 ---
TMHHX 3 0.86 1.12 0.37 0.42 ---
ACCUMULATIVE
TIMER
TTIM 3 16.1 17.0 21.4 21.4 ---
10.9 11.4 14.8 14.8 When resetting
8.5 8.7 10.7 10.7 When interlock-
ing
TTIMX 3 16.1 17.0 21.4 21.4 ---
10.9 11.4 14.8 14.8 When resetting
8.5 8.7 10.7 10.7 When interlock-
ing
LONG TIMER TIML 4 to 5 7.6 10.0 12.8 12.8 ---
6.2 6.5 7.8 7.8 When interlock-
ing
TIMLX 4 to 5 7.6 10.0 12.8 12.8 ---
6.2 6.5 7.8 7.8 When interlock-
ing
MULTI-OUTPUT
TIMER
MTIM 4 20.9 23.3 26.0 26.0 ---
5.6 5.8 7.8 7.8 When resetting
MTIMX 4 20.9 23.3 26.0 26.0 ---
5.6 5.8 7.8 7.8 When resetting
COUNTER CNT 3 0.56 0.88 0.37 0.42 ---
CNTX 3 0.56 0.88 0.37 0.42 ---
REVERSIBLE
COUNTER
CNTR 3 16.9 19.0 20.9 20.9 ---
CNTRX 3 16.9 19.0 20.9 20.9 ---
RESET TIMER/
COUNTER
CNR 3 9.9 10.6 13.9 13.9 When resetting
1 word
4160 4160 5420 5420 When resetting
1,000 words
CNRX 3 9.9 10.6 13.9 13.9 When resetting
1 word
4160 4160 5420 5420 When resetting
1,000 words
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
