CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3-22 Network Instructions
4-3-23 File Memory Instructions
4-3-24 Display Instructions
4-3-25 Clock Instructions
4-3-26 Debugging Instructions
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
NETWORK SEND SEND 4 84.4 123.9 123.9 123.9 ---
NETWORK RECEIVE RECV 4 85.4 124.7 124.7 124.7 ---
DELIVER COMMAND CMND 4 106.8 136.8 136.8 136.8 ---
EXPLICIT MESSAGE SEND EXPLT 4 127.6 190.0 --- --- ---
EXPLICIT GET ATTRIBUTE EGATR 4 123.9 185.0 --- --- ---
EXPLICIT SET ATTRIBUTE ESATR 3 110.0 164.4 --- --- ---
EXPLICIT WORD READ ECHRD 4 106.8 158.9 --- --- ---
EXPLICIT WORD WRITE ECHWR 4 106.0 158.3 --- --- ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
READ DATA FILE FREAD 5 391.4 632.4 684.1 684.1 2-character directory +
file name in binary
WRITE DATA FILE FWRIT 5 387.8 627.0 684.7 684.7 2-character directory +
file name in binary
WRITE TEXT FILE TWRIT 5 390.1 619.1 --- ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
DISPLAY MES-
SAGE
MSG 3 10.1 14.2 14.3 14.3 Displaying message
8.4 11.3 11.3 11.3 Deleting displayed
message
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
CALENDAR ADD CADD 4 38.3 201.9 209.5 209.5 ---
CALENDAR SUBTRACT CSUB 4 38.6 170.4 184.1 184.1 ---
HOURS TO SECONDSSEC 3 21.429.335.835.8---
SECONDS TO HOURS HMS 3 22.2 30.9 42.1 42.1 ---
CLOCK ADJUSTMENTDATE 2 60.587.495.995.9---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
Trace Memory Sampling TRSM 1 80.4 120.0 120.0 120.0 Sampling 1 bit
and 0 words
848.1 1060 1060 1060 Sampling 31
bits and 6 words
To Next Page
