CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3 CS-series Instruction Execution Times and Number of Steps
4
4-3-27 Failure Diagnosis Instructions
4-3-27 Failure Diagnosis Instructions
4-3-28 Other Instructions
4-3-29 Block Programming Instructions
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
FAILURE ALARM FAL 3 15.4 16.7 16.7 16.7 Recording errors
179.8 244.8 244.8 244.8 Deleting errors
(in order of priority)
432.4 657.1 657.1 657.1 Deleting errors
(all errors)
161.5 219.4 219.4 219.4 Deleting errors
(individually)
SEVERE FAIL-
URE ALARM
FALS 3 --- --- --- --- ---
FAILURE POINT
DETECTION
FPD 4 140.9 202.3 202.3 202.3 Bit address output,
time monitored
163.4 217.6 217.6 217.6 Bit address output,
first error detection
185.2 268.9 268.9 268.9 Message characters
output, time monitored
207.5 283.6 283.6 283.6 Message characters
output, first error
detection
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
SET CARRY STC 1 0.06 0.06 0.12 0.12 ---
CLEAR CARRY CLC 1 0.06 0.06 0.12 0.12 ---
SELECT EM BANK EMBC 2 14.0 15.1 15.1 15.1 ---
EXTEND MAXIMUM
CYCLE TIME
WDT 2 15.0 19.7 19.7 19.7 ---
SAVE CONDITION
FLAGS
CCS 1 8.6 12.5 --- --- ---
LOAD CONDITION
FLAGS
CCL 1 9.8 13.9 --- --- ---
CONVERT ADDRESS
FROM CV
FRMCV 3 13.6 19.9 --- --- ---
CONVERT ADDRESS
TO CV
TOCV 3 11.9 17.2 --- --- ---
DISABLE PERIPH-
ERAL SERVICING
IOSP --- 13.9 19.8 --- --- ---
ENABLE PERIPHERAL
SERVICING
IORS --- 63.6 92.3 --- --- ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
BLOCK PROGRAM
BEGIN
BPRG 2 12.1 13.0 13.0 13.0 ---
BLOCK PROGRAM
END
BEND 1 9.6 12.3 13.1 13.1 ---
BLOCK PROGRAM
PAUS E
BPPS 2 10.6 12.3 14.9 14.9 ---
BLOCK PROGRAM
RESTART
BPRS 2 5.1 5.6 8.3 8.3 ---
