CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
Appendix A List of Instructions by Function Code
App
098 NETWORK RECEIVE RECV @RECV --- --- 935
099 MACRO MCRO @MCRO --- --- 693
114 SIGNED BINARY
COMPARE
CPS --- --- !CPS 264
115 DOUBLE SIGNED
BINARY COMPARE
CPSL --- --- --- 264
116 DOUBLE AREA
RANGE COMPARE
ZCPL --- --- --- 276
117 SIGNED AREA
RANGE COMPARE
ZCPS --- --- --- 280
118 DOUBLE SIGNED
AREA RANGE COM-
PA RE
ZCPSL --- --- --- 280
160 2’S COMPLEMENT NEG @NEG --- --- 387
161 DOUBLE 2’S
COMPLEMENT
NEGL @NEGL --- --- 387
162 ASCII TO HEX HEX @HEX --- --- 405
174 DOUBLE FIND MAXI-
MUM
MAXL @MAXL --- --- 592
175 DOUBLE FIND MINI-
MUM
MINL @MINL --- --- 599
176 FIND MAXIMUM
FLOATING
MAXF @MAXF --- --- 595
177 FIND MINIMUM
FLOATING
MINF @MINF --- --- 601
178 FIND DOUBLE MAXI-
MUM FLOATING
MAXD @MAXD --- --- 597
179 FIND DOUBLE MINI-
MUM FLOATING
MIND @MIND --- --- 603
180 FRAME CHECKSUM FCS @FCS --- --- 608
181 DATA SEARCH SRCH @SRCH --- --- 583
182 FIND MAXIMUM MAX @MAX --- --- 588
183 FIND MINIMUM MIN @MIN --- --- 588
184 SUM SUM @SUM --- --- 605
190 PID CONTROL PID --- --- --- 640
191 PID CONTROL WITH
AUTOTUNING
PIDAT --- --- --- 651
194 SCALING SCL @SCL --- --- 672
195 AVERAGE AVG --- --- --- 683
203 UNSIGNED ONE-
WORD RECORD
SORT
RSORT @RSORT --- --- 630
204 UNSIGNED TWO-
WORD RECORD
SORT
RSORT2 @RSORT2 --- --- 634
205 UNSIGNED FOUR-
WORD RECORD
SORT
RSORT4 @RSORT4 --- --- 637
210 DIGITAL SWITCH
INPUT
DSW --- --- --- 807
211 TEN KEY INPUT TKY @TKY --- --- 811
212 HEXADECIMAL KEY
INPUT
HKY --- --- --- 814
213 MATRIX INPUT MTR --- --- --- 818
214 7-SEGMENT DISPLAY
OUTPUT
7SEG --- --- --- 822
216 ANALOG INPUT
DIRECT CONVER-
SION
AIDC @AIDC --- --- 826
217 ANALOG OUTPUT
DIRECT CONVER-
SION
AODC @AODC --- --- 829
218 PCU HIGH-SPEED
POSITIONING
NCDMV @NCDMV --- --- 832
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
