CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
417 DOUBLE BCD
SUBTRACT WITH
CARRY
–BCL @–BCL --- --- 368
420 SIGNED BINARY
MULTIPLY
* @* --- --- 370
421 DOUBLE SIGNED
BINARY MULTIPLY
*L@*L --- --- 370
422 UNSIGNED BINARY
MULTIPLY
*U@*U --- --- 372
423 DOUBLE UNSIGNED
BINARY MULTIPLY
*UL @*UL --- --- 372
424 BCD MULTIPLY *B@*B --- --- 374
425 DOUBLE BCD
MULTIPLY
*BL @*BL --- --- 374
430 SIGNED BINARY
DIVIDE
/@/--- --- 376
431 DOUBLE SIGNED
BINARY DIVIDE
/L @/L --- --- 376
432 UNSIGNED BINARY
DIVIDE
/U @/U --- --- 378
433 DOUBLE UNSIGNED
BINARY DIVIDE
/UL @/UL --- --- 378
434 BCD DIVIDE /B @/B --- --- 380
435 DOUBLE BCD DIVIDE /BL @/BL --- --- 380
448 FLOATING POINT TO
ASCII
FSTR @FSTR --- --- 505
449 ASCII TO FLOATING
POINT
FVAL @FVAL --- --- 510
450 FLOATING TO 16-BIT FIX @FIX --- --- 472
451 FLOATING TO 32-BIT FIXL @FIXL --- --- 472
452 16-BIT TO FLOATING FLT @FLT --- --- 474
453 32-BIT TO FLOATING FLTL @FLTL --- --- 474
454 FLOATING-POINT
ADD
+F @+F --- --- 476
455 FLOATING-POINT
SUBTRACT
–F @–F --- --- 476
456 FLOATING-POINT
MULTIPLY
*F@*F --- --- 476
457 FLOATING-POINT
DIVIDE
/F @/F --- --- 476
458 DEGREES TO
RADIANS
RAD @RAD --- --- 480
459 RADIANS-TO
DEGREES
DEG @DEG --- --- 482
460 SINE SIN @SIN --- --- 484
461 COSINE COS @COS --- --- 484
462 TANGENT TAN @TAN --- --- 484
463 ARC SINE ASIN @ASIN --- --- 491
464 ARC COSINE ACOS @ACOS --- --- 491
465 ARC TANGENT ATAN @ATAN --- --- 491
466 SQUARE ROOT SQRT @SQRT --- --- 494
467 EXPONENT EXP @EXP --- --- 496
468 LOGARITHM LOG @LOG --- --- 498
469 MOVE FLOATING-
POINT (SINGLE)
MOVF @MOVF --- --- 514
470 SIGNED BCD TO
BINARY
BINS @BINS --- --- 414
471 SIGNED BINARY TO
BCD
BCDS @BCDS --- --- 419
472 DOUBLE SIGNED
BCD TO BINARY
BISL @BISL --- --- 414
473 DOUBLE SIGNED
BINARY TO BCD
BDSL @BDSL --- --- 419
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
