Omron CJ - INSTRUCTIONS - Page 1273

1235
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
Appendix A List of Instructions by Function Code
App
474 GRAY CODE CON-
VERSION
GRY@GRY--- --- 423
475 HIGH-SPEED SINE SINQ @SINQ --- --- 487
476 HIGH-SPEED COSINE COSQ @COSQ --- --- 487
477 HIGH-SPEED TAN-
GENT
TANQ @TANQ --- --- 487
478 GRAY CODE TO
BINARY CONVERT
GRAY_BIN @GRAY_BIN --- --- 428
479 DOUBLE GRAY CODE
TO BINARY CONVERT
GRAY_BINL @GRAY_BINL --- --- 428
480 BINARY TO GRAY
CODE CONVERT
BIN_GRAY @BIN_GRAY --- --- 430
481 DOUBLE BINARY TO
GRAY CODE CON-
VERT
BIN_GRAYL @BIN_GRAYL --- --- 430
486 SCALING 2 SCL2 @SCL2 --- --- 676
487 SCALING 3 SCL3 @SCL3 --- --- 680
490 DELIVER COMMAND CMND @CMND --- --- 944
491 NETWORK SEND 2 SEND2 @SEND2 --- --- 931
492 NETWORK RECEIVE
2
RECV2 @RECV2 --- --- 940
493 DELIVER COMMAND
2
CMND2 @CMND2 --- --- 952
498 DOUBLE MOVE MOVL @MOVL --- --- 283
499 DOUBLE MOVE NOT MVNL @MVNL --- --- 286
502 EXPANDED BLOCK
COMPARE
BCMP2 @BCMP2 --- --- 273
510 CONDITIONAL JUMP CJP --- --- --- 199
511 CONDITIONAL JUMP CJPN --- --- --- 199
512 FOR-NEXT LOOPS FOR --- --- --- 205
513 FOR-NEXT LOOPS NEXT --- --- --- 205
514 BREAK LOOP BREAK --- --- --- 208
515 MULTIPLE JUMP JMP0 --- --- --- 202
516 MULTIPLE JUMP END JME0 --- --- --- 202
517 MULTI-INTERLOCK
DIFFERENTIATION
HOLD
MILH --- --- --- 187
518 MULTI-INTERLOCK
DIFFERENTIATION
RELEASE
MILR --- --- --- 187
519 MULTI-INTERLOCK
CLEAR
MILC --- --- --- 187
520 NOT NOT --- --- --- 149
521 CONDITION ON UP --- --- --- 150
522 CONDITION OFF DOWN --- --- --- 150
530 MULTIPLE BIT SET SETA @SETA --- --- 172
531 MULTIPLE BIT RESET RSTA @RSTA --- --- 172
532 SINGLE BIT SET SETB @SETB --- !SETB 174
533 SINGLE BIT RESET RSTB @RSTB --- !RSTB 174
534 SINGLE BIT OUTPUT OUTB @OUTB --- !OUTB 176
540 ONE-MS TIMER TMHH --- --- --- 225
541 TENTH-MS TIMER TIMU --- --- --- 228
542 LONG TIMER TIML --- --- --- 237
543 MULTI-OUTPUT
TIMER
MTIM --- --- --- 240
544 HUNDREDTH-MS
TIMER
TMUH --- --- --- 231
545 RESET TIMER/
COUNTER
CNR @CNR --- --- 250
546 COUNTER CNTX --- --- --- 244
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
